HPM Vivo 350VA 3 Wire Push Button Dimmer Dark Grey

Vivo HPM

HPM Vivo 350VA 3 Wire Push Button Dimmer Dark Grey

REF. EV400PB3GR Barcode. 9321001465768
1 Year Warranty
Download product sheet
You can compare up to 4 products
Features
  • Kickstart mode suitable for modern light sources
  • Suitable for all loads including LED dimmable devices*
  • 3 Wire technology soft touch electronic push button
  • Multi-way dimming option (Slave Dimmer Cat No. EM800SLAVE series)
  • Programmable LED indicator
User Recommendations
  • Suitable for all commercial and residential installations such as kitchens, bedrooms, offices, retail, hospitality and education facilities
  • Cut-out size: 56 x 96mm
Overview
The HPM Vivo 350VA 3 Wire Push Button Dimmer is the ideal solution for those seeking precise control over their room lighting. Featuring programmable dimming options, it allows you to effortlessly adjust light intensity to suit your needs. The built-in LED indicator makes it easy to locate the switch in the dark, while the soft start mode provides a smooth transition to your preferred lighting level. With its sleek, square design and interchangeable cover plate, this wall plate not only complements any decor but also lets you customise it to match your style.

Quality You Can Trust

Installation
  • Oval 84mm fixing points - make it easier to straighten-up products at the last minute
Convenient Functionality
  • Programmable Soft Start mode, Max/Min light levels
Unique Characteristics
  • Dimming level memory function
  • Short circuit and overload protection
  • Program parameters stored in a non-volatile memory

Technical Specifications

Assembly arrangement Basic element with full cover plate
Method of operation Push button
Number of units 1
Mounting method Surface mounted
Type of fastening Mounting with screw
Material Plastic
Colour Grey
Device width 119 mm
Device height 85 mm
Device depth 10 mm
Voltage type AC

Documentation

1 document
Technical Sheet
